The Toolkit

Hands --M.C. Escher (Click to see full size)

In addition to ClearCase and ClearDDTS, our main Software Configuration Management and Problem Tracking tools, we have a bag of helpful tools and utilities.

Here's a Tool Catalog you might find useful:

• Helpful aliases. These are some command definitions that will help you navigate and perform some useful tasks.

  Find any element in any vob:
  alias locate /packages/cc_site/bin/locate
  46% locate foo
  /vob/fx/src/components/foo/foo.C
  /vob/fx/src/components/foo/foo.h
  ...



  Finding a string in a VOB element:
  alias fgrc 'find . -type f -name "*[Cc]" -print | xargs grep \!*'
  alias fgrh 'find . -type f -name "*h" -print | xargs grep \!*'
  alias fgrm 'find . -type f -name "[Mm]akefile" -print | xargs grep \!*'
  alias fgr 'find . -type f -name "*[Cch]" -print | xargs grep \!*'
  47% cd src
  /vob/fx/src
  48% fgrm license
  ./console/Makefile:LLDLIBS = -lfoolicense -lfoolog -lka $(ROGUELIB)
  ./main/Makefile:fooLIBS = -lfoolicense
  ...



  List the files which have a specific branch:
  alias lsbranch cleartool find -avobs -branch \'brtype\(\!\:1\)\' -print -nxname \!:2\*
  49% lsbranch wilder_20114
  /vob/utilities/build/monitorcal_version
  /vob/utilities/build/specfile_monitorcal
  ...



  List branches owned by me:
  alias mybranches 'cleartool lstype -brt -short|grep $USER'
  38% mybranches
  wilder2_12351
  wilder3_12351
  wilder_11496 (locked)
  ...



  Lock specified branches:
  alias lockbranch 'cleartool lock -brtype \!$'
  41% lockbranch `mybranches`
  Locked branch type "wilder2_12351".
  Locked branch type "wilder3_12351".
  cleartool: Error: Object is already locked.
  ...



  Create a file in ~/conspecs of a view's config spec:
  alias storeview /usr/atria/bin/cleartool catcs -tag \!\$ \>~/conspecs/\!\$.cs
  42% storeview wilder_20148



• Some utilities:

  Find any element in any vob:
  alias locate /packages/cc_site/bin/locate
  46% locate cifoolicense
  /vob/fx/src/components/foolicense/CifooLicense.C
  /vob/fx/src/components/foolicense/CifooLicense.h
  ...



  A neat diff for VOB elements (see /packages/cc_site/docs/ctdiff.doc for man page):
  alias ctdiff /packages/cc_site/sgi_bin/ctdiff
  50% ctdiff
  Usage: ctdiff [ [-version version-spec] | [-brpoint] | [-label label-type] ]
  {cleartool diff arguments} { pname ... | < list_of_pnames }
  NOTE: All flags may be abbreviated to three characters.



  An easy way to remove empty branches (file branches which have only a version zero):
  alias rmempty /packages/cc_site/sgi_bin/rm_empty_branch
  50% rmempty
  Usage: rm_empty_branch [-f[orce]] _branch_specifier_
  -f[orce] will remove the branch without confirmation,
  for example,
  rm_empty_branch -f /vob/fx/src/Makefile@@/main/sjk_brtype
  _branch_specifier_ must appear as the the last argument.
